MBT Surgical Instruments’ Implant Surgical Kit combines precision bone compactors, depth-marked terphine burs, and specialized sinus-lift elevators to streamline osteotomy preparation, graft stabilization, and sinus membrane elevation. Crafted from surgical-grade stainless steel with knurled handles, each instrument delivers tactile feedback, corrosion resistance, and full autoclavability for safe reuse.

Product Specifications:

• Material: Surgical-grade stainless steel

• Handle: Knurled stainless-steel shaft

• Sterilization: Fully autoclavable

• Applications: Bone compaction, osteotomy depth control, sinus membrane elevation

Bone Compactors:

• 2319 (Fig. 1): Straight tip, 6 11⁄16″ overall (Ø 1⁄16″ concave tip)

• 2320 (Fig. 2): Angled tip, 6 7⁄8″ overall (Ø 1⁄16″ concave tip)

• 2321 (Fig. 3): Reverse-angled tip, 6 11⁄16″ overall (Ø 1⁄16″ concave tip)

• 2322 (Lucas Fig. 88): Dual-angle tip, 6 11⁄16″ overall with replaceable ¼″–5∕16″ compactor heads

• 2323 (Fig. 1 compactor head): Ø 3⁄16″–¼″ replaceable head

• 2324 (Fig. 2 compactor head): Ø ¼″–5∕16″ replaceable head

Terphine Burs with Depth Marking (approx. 5 5⁄8″ shaft):

• 2325: Ext. Ø 3⁄16″ (Int. Ø 1⁄8″)

• 2326: Ext. Ø ¼″ (Int. Ø 5⁄32″)

• 2327: Ext. Ø 5∕16″ (Int. Ø 5⁄16″)

• 2328: Ext. Ø 7⁄16″ (Int. Ø 3⁄8″)

Sinus-Lift Elevators (all approx. 6 11⁄16″–7″ overall):

• 2329 (Fig. 1): Curved leaf tip

• 2330 (Fig. 2): Narrow paddle tip

• 2331 (Fig. 3): Broad angled tip

• 2332 (Fig. 4): Slim sharp tip

• 2333 (Fig. 5): Angled spoon tip

• 2334 (Fig. 6): Hooked sharp tip

• 2335 (Fig. 7): Rounded sharp tip

• 2336 (Fig. 8): Tapered small spoon tip

• 2337 (Fig. 9): Flat broad tip

Why Clinicians Choose This Kit:

• Knurled shafts for slip-resistant control during compaction and elevation

• Replaceable compactor heads and depth-marked burs for reproducible results

• Variety of elevator tip geometries for safe sinus membrane detachment

• Fully autoclavable, surgical-grade construction for OR compliance

Key Features:
✅ Four compactor heads (Ø 3⁄16″–5∕16″) on straight and angled bodies
✅ Four terphine burs (Ø 3⁄16″–7⁄16″) with laser-etched depth rings
✅ Nine sinus-lift elevators covering curved, spoon, hook, and paddle tips
✅ Ergonomic knurled handles for tactile feedback
✅ Surgical-grade stainless steel, fully autoclavable
